After 24 months of R&D we are pleased to launch our HD 2MP MegaMitter which can transmit AHD CCTV cameras wirelessly. As most CCTV cameras have 4-in-1 selectable outputs including AHD, and similarly most DVRs can detect and display AHD cameras the MegaMitter is a universal wireless transmitter for most installations.

The quality electronics of the MegaMitter digitise the signal resulting in almost no loss of picture quality for stunning results. For the widest possible DVR integration MegMitters use the H264 codec therefore having a wide compatibility with both older and newer DVRs. The robust aluminium case adds a great toughness and feel to the product as well as shielding any interference for the best possible picture quality.

The MegaMitters are sold in pairs, and one acts as a transmitter and the other a receiver for a one 2 one transmission. Using the antennas supplied, you can expect to get good results up to 200M line of sight with no obstructions in between the TX & RX. *For greater distances you may need to consider upgrading the antennas to directional ones which are sold as extras.

Up to 4 pairs of MegaMitters can be used on the same site but it is recommended to use directional antennas when using multiple sets.

The MegaMitters are designed to work on 12V DC so they are easy to power using standard 12V PSUs.

Top Tip

If you usually use TVI, simply set your CCTV camera to AHD mode and the DVR should. automatically detect the AHD input, if not go into the DVR menu and select AHD.

TECHNICAL SPECIFICATION

• Power 12v Tx 250mA Rx 140mA
• Video Format CVBS (PAL/NTSC) / AHD 720p / AHD 1080p
• Delay 150mS Max
• Freq - 2.4Ghz range
• Range - 200M (as supplied) - 1KM (with additional aerials)
• IP rating IP66 (providing connections are made IP66)
• Size - 110 x 95 x 25mm
• Antenna mount - rp-SMA
